| Product Photo | ETC Part NO. | Description | Length (mm) |
Width (mm) |
Height (mm) |
Size Code | Data Sheet |
|---|---|---|---|---|---|---|---|
|
SPI0402H | Shielded SMT Power Inductor SPI-H Series |
4.50 | 4.10 | 2.00 |  |
|
| SPI0502H | 5.50 | 5.00 | 2.00 | ||||
| SPI0503H | 5.50 | 5.00 | 3.00 | ||||
| SPI0602H | 7.60 | 6.80 | 2.00 | ||||
| SPI0625H | 7.60 | 6.80 | 2.50 | ||||
| SPI0603H | 7.60 | 6.80 | 3.20 | ||||
| SPI0604H | 7.60 | 6.90 | 4.00 | ||||
| SPI0605H | 7.60 | 6.80 | 5.00 | ||||
| SPI1003H | 11.50 | 10.60 | 3.00 | ||||
| SPI1004H | 11.50 | 10.30 | 4.20 | ||||
| SPI1005H | 11.50 | 10.60 | 5.00 | ||||
| SPI1235H | 13.80 | 12.90 | 3.70 | ||||
| SPI1205H | 13.80 | 12.90 | 5.00 | ||||
| SPI1207H | 13.80 | 12.90 | 6.50 | ||||
|
SPI0603HS | Shielded SMT Power Inductor SPI-H Series |
7.30 | 6.80 | 3.00 | |
|
|
SPI0402N | Shielded SMT Power Inductor SPI-N Series |
5.00 | 4.50 | 2.00 | |
|
| SPI0502N | 6.00 | 5.30 | 2.00 | ||||
| SPI0503N | 6.00 | 5.30 | 3.00 | ||||
| SPI0618N | 7.60 | 6.90 | 1.80 | ||||
| SPI0624N | 7.60 | 6.90 | 2.40 | ||||
| SPI0603N | 7.60 | 6.90 | 3.00 | ||||
| SPI1003N | 11.50 | 10.60 | 3.00 | ||||
| SPI1004N | 11.50 | 10.60 | 4.00 | ||||
| SPI1005N | 11.50 | 10.60 | 5.00 | ||||
| SPI1205N | 13.80 | 12.90 | 5.00 | ||||
|
SPI0603NS | Shielded SMT Power Inductor SPI-N Series |
7.30 | 6.80 | 3.00 | |
|
|
SPI201610 | Shielded SMT Power Inductor SPI Series |
2.20 | 1.80 | 1.00 | |
|
| SPI201612 | 2.20 | 1.80 | 1.20 | ||||
| SPI252010 | 2.70 | 2.20 | 1.00 | ||||
| SPI252012 | 2.70 | 2.20 | 1.20 | ||||
|
SPI201610P | Shielded SMT Power Inductor SPI-P Series |
2.20 | 1.80 | 1.00 | |
|
| SPI201612P | 2.20 | 1.80 | 1.20 | ||||
| SPI252010P | 2.70 | 2.20 | 1.00 | ||||
| SPI252012P | 2.70 | 2.20 | 1.20 | ||||
|
SPI0310 | Shielded SMT Power Inductor SPI Series |
3.60 | 3.20 | 1.00 | |
|
| SPI0312 | 3.60 | 3.20 | 1.20 | ||||
| SPI0315 | 3.60 | 3.20 | 1.50 | ||||
| SPI0302 | 3.60 | 3.20 | 2.00 | ||||
|
SPI0410 | Shielded SMT Power Inductor SPI Series |
4.60 | 4.20 | 1.00 | |
|
| SPI0412 | 4.60 | 4.20 | 1.20 | ||||
| SPI0415 | 4.60 | 4.20 | 1.50 | ||||
| SPI0402 | 4.60 | 4.20 | 2.00 | ||||
|
SPI0510 | Shielded SMT Power Inductor SPI Series |
5.70 | 5.40 | 1.00 | |
|
| SPI0512 | 5.70 | 5.40 | 1.20 | ||||
| SPI0515 | 5.70 | 5.40 | 1.50 | ||||
| SPI0518 | 5.70 | 5.40 | 1.80 | ||||
| SPI0502 | 5.70 | 5.40 | 2.00 | ||||
|
SPI0412F | Shielded SMT Power Inductor SPI-F Series |
4.60 | 4.20 | 1.20 | |
|
| SPI0402F | 4.60 | 4.20 | 2.00 | ||||
|
SPI0518F | Shielded SMT Power Inductor SPI-F Series |
5.70 | 5.40 | 1.80 | |
|
|
SPI0603FS | Shielded SMT Power Inductor SPI-F Series |
7.30 | 6.80 | 3.00 | |
|
| SPI0804F | 8.90 | 8.25 | 4.00 | ||||
| SPI1004F | 11.50 | 10.30 | 4.00 | ||||
| SPI1205F | 13.90 | 12.90 | 5.00 | ||||
| SPI1265F | 13.90 | 12.90 | 6.50 | ||||
| SPI1704F | 17.80 | 17.30 | 4.00 | ||||
| SPI1707F | 17.80 | 17.30 | 7.00 | ||||
| SPI2213F | 23.50 | 22.50 | 13.00 | ||||
|
SPI0603BS | Shielded SMT Power Inductor SPI-B Series |
7.30 | 6.80 | 3.00 | |
|
| SPI0804B | 8.90 | 8.35 | 4.00 | ||||
| SPI1004B | 11.50 | 10.30 | 4.00 | ||||
| SPI1205B | 13.90 | 12.90 | 5.00 | ||||
| SPI1265B | 13.90 | 12.90 | 6.50 | ||||
| SPI1704B | 17.80 | 17.30 | 4.00 | ||||
| SPI1707B | 17.80 | 17.30 | 7.00 | ||||
| SPI2213B | 23.50 | 22.50 | 13.00 | ||||
|
SPI0503FW | Shielded SMT Power Inductor SPI-FW Series |
5.75 | 5.40 | 3.00 | |
|
|
SPI0603FW | Shielded SMT Power Inductor SPI-FW Series |
7.30 | 6.80 | 3.00 | |
|
| SPI1004FW | 11.50 | 10.30 | 4.00 | ||||
| SPI1005FW | 11.50 | 10.30 | 5.00 |
